MIL-DTL-50714C (OS)
4.4.1.1 Submission of product. Unless otherwise specified by the contracting activity, formation and
identification of lots shall be in accordance with ANSI/ASQ Z1.4.
TABLE II. Sensitivity test sample size.
Ignition Device Sensitivity
Lot Size
Sample Size
3 to 15
6
16 to 25
8
26 to 40
10
41 to 65
14
66 to 110
20
111 to 180
30
181 to 300
50
301 to 500
60
501 to 800
70
801 to 1300
80
over 1300
100
4.4.1.2 Size of lot. A lot shall consist of an identifiable group of assembled units containing metal parts
assemblies produced by a homogeneous process and loaded with acceptable explosive and pyrotechnic
components.
4.4.2 Examination. One hundred percent examination shall be performed for all critical defects. Examination
for major and minor defects shall be performed in accordance with the classification of defects. Four power
(4x) magnification may be used for inspection of such defects as burrs and foreign matter. When compliance
with the applicable requirement is in doubt as a result of visual examination, the characteristic shall be
measured or gauged to determine applicability. All nonconforming material shall be rejected.
4.4.2.1 Pin, Firing, Drawing 11738410, covering a detail of Drawing 11731492.
Characteristics
Defect
Method of Inspection
Critical
None defined
Major
101
True position of O-ring groove with body
Gage
102
Concentricity of striker with body
Gage
103
True position of shear pin hole with body
Gage
104
Diameter of O-ring groove, min
Gage
6
