TABLE I. Production inspections.
6GUV 5GSWGPEG
6GUV
4GSWKTGOGPV
2CTCITCRJ
2CTCITCRJ
8KUWCN
CPF
4CFKQITCRJKE KPURGEVKQP
.GCMCIG
&GOCIPGVK\CVKQP
3.4.1 Visual inspection. Cartridges shall be free of the following defects: illegible, missing or inaccurate
identification markings, damage, burrs, dents, sharp edges, or other defects which may prevent
installation of the cartridge into its designated end items. Each cartridge shall meet the requirements of
3.3, 3.6, and Drawing 850AS895.
3.4.2 Radiographic examination. When radiographically examined in accordance with 4.3.2, the
cartridge shall show proper assembly, presence of parts, and proper thread form. The radiographic
inspection shall show no defective or improperly assembled components; foreign matter; cracks;
abnormal voids or other abnormalities which could affect the performance of the unit.
3.4.3 Leakage. The leakage rate of each cartridge shall not exceed 1.0 x 10-5 cc/sec of air when tested in
accordance with 4.3.3.
3.4.4 Demagnetization. The cartridges shall not deflect an approved pilot's standby compass more than 3
degrees in either direction when passed in front of the compass when tested in accordance with 4.3.4.
3.4.4.1 Degauss. If a cartridge deflects the compass more than 3 degrees, the cartridge shall be degaussed
and the test repeated until acceptable results are obtained.
3.5 Cartridge performance. The cartridge shall meet all requirements of 3.5.1 through 3.5.6 and the
acceptance criteria of 4.4.
3.5.1 Vibration. The cartridge shall not initiate or incur any internal/external damage or degradation
when vibration cycles are applied in accordance with 4.3.5.
3.5.2 Temperature and humidity cycling (T&H). The cartridge shall not initiate or incur any internal
or external degradation or damage when a T&H cycle is applied in accordance with 4.3.6.
3.5.3 High altitude. The cartridge shall not degrade in performance when submitted to the conditions of
4.3.7.
