MIL-DTL-60286C
3.6.1.1 Initiation. The initiator shall be fired by a source delivering an output pressure of 700 +25, -0
pounds per square inch gage (psig) at 70 ± 5bF.
3.6.2 Misfires. There shall be no misfires.
3.6.3 Mechanical failures. The initiator shall function without mechanical failure (see 6.4.2).
TABLE I. Pressure values.
Temperature (bF)
Pressure (psig)
Ignition delay milliseconds,
max
Minimum
Maximum
-60 to -70
500
1425
65
65 to 75
600
1550
65
195 to 205
700
1700
65
3.7 Workmanship. Initiators shall be free of cracks, splits, or other defects which might prevent proper
mating with connecting parts or proper functioning of the device.
3.7.1 Metal defects. All components shall be free from cracks, splits, cold shuts, inclusions, porosity, or
any similar defect.
3.7.2 Burr. No part shall have a burr which might interfere with the assembly or function of the item or
which might be injurious to personnel handling the item.
3.7.3 Foreign matter. No part or assembly shall contain chips, dirt, grease, rust, corrosion, or other
foreign matter.
4. QUALITY ASSURANCE PROVISIONS
4.1 Classification of inspections. The inspection requirements specified herein are classified as
follows:
a. Conformance inspection (see 4.2).
4.1.2 Quality assurance terms and definitions. Reference shall be made to ASQC A8402 to define the
quality assurance terms used.
4.1.3 Inspections. Inspections shall be in accordance with MIL-A-2550 and ASTM E1742.
4.2 Conformance inspection provisions.
4.2.1 Lot.
4.2.1.1 Submission or product. Unless otherwise specified by the contracting activity, formation, and
identification of lots shall be in accordance with ASQC Z1.4.
4
