MIL-DTL-50699B
4.4.3 Temperature conditioning for ballistic test. The sample shall be temperature conditioned
and tested to determine compliance with 3.8.1. The sample for firing shall be conditioned to the
temperatures specified in table III.
TABLE III. Temperature conditioning for first article sample.
Temperature (°F)
Not vibrated
Vibrated
-60 to -70
3
4
65 to 75
3
4
195 to 205
3
4
4.4.4 First article failure. Failure of the sample to comply with the requirements of the drawings
and specifications shall result in first article sample disapproval.
4.5 Quality conformance inspection.
4.5.1 Lot.
4.5.1.1 Submission of product. The product shall be submitted in accordance with ANSI/ASQ
Z1.4.
4.5.1.2 Lot size. The production lot size shall be as specified in the contract (see 6.2).
4.5.2 Examination. One hundred percent examination shall be performed for all critical defects.
Examination for major and minor defects shall be performed in accordance with the classification of
defects. Four power (4x) magnification may be used for inspection of such defects as burr and foreign
matter. When compliance with the applicable requirement is in doubt as a result of visual examination, the
characteristic shall be measured or gauged to determine acceptability. All nonconforming material shall be
rejected.
4.5.2.1 Pin, Firing, Drawing 11738410, covering a detail of Drawing 11731492.
Characteristics
Defect
Method of Inspection
Critical
None defined
Major
101
True position of O-ring groove with body
Gage
102
Concentricity of striker with body
Gage
103
True position of shear pin hole with body
Gage
104
Diameter of O-ring groove, min
Gage
105
Diameter of body, min
Gage
106
Diameter of striker
Gage
107
Length of striker, min
Gage
108
Diameter of shear pin hole, max
Gage
109
Depth of shear pin hole, max
Gage
110
Width of O-ring groove
Gage
6
