MIL-DTL-81984C(OS)
removal from conditioning. The cartridges allocated for the low temperature and high temperature tests
shall be conditioned at !65 ± 5EF and 200 ± 5EF, respectively for not less than 6 nor more than 24 hours
and fired within 3 minutes after removal from conditioning. All first article cartridge firings shall be
conducted in a test fixture in accordance with the requirements of 4.5.7.1. All cartridges shall fire and
produce results within the limits specified in 3.8.1 and 3.8.3, except that the upper (U) and lower (L)
limits of maximum pressure in pounds per square inch for cartridges fired at !65EF and 200EF shall be
U = 7630 and L = 6220. The pressure limits of 3.8.1 apply for all cartridges fired at 70EF.
4.3.3 Failure. Failure of any cartridge shall be cause for rejection of the first article sample.
4.4 Quality conformance inspection. Quality conformance inspection shall consist of the tests
specified in table I.
TABLE I. Quality conformance tests and examinations.
Item
Nature of test
Requirement para.
Test para.
Classification
Primary component
Single lot verification
3.4
4.4.1
M101
Ignition element
Age and acceptance verification
3.5
4.5.1
C1
Propellant charge
Type and weight
3.6.1
-
M102
Smokeless powder
Condition
3.6.3
4.5.2
M103
Cartridge
Visual examination
3.10
4.5.3
M104
Cartridge
Bridge circuit resistance
3.7.1
4.5.4
C2
Cartridge
Leakage
3.7.2
4.5.5
C3
Cartridge
X-ray
3.7.3
4.5.6
C4
Cartridge
Ballistics
3.8
4.5.7
C5
Cartridge
Ballistics (change in propellant lot)
3.9
4.7
C6
4.4.1 Lot size. Unless otherwise specified (see 6.2), the production lot size shall be not less than 1301
and not greater than 3200. Only primary components from a single lot shall be used in a production lot
of cartridges; however, one primary component production lot may be used in more than one cartridge
production lot.
4.4.2 Sampling. Unless otherwise specified (see 6.2), sampling shall be in accordance with table II.
4.4.3 Classification of characteristics. The characteristics verified by the tests and examinations
herein are classified as critical, major, or minor in accordance with DOD-STD-2102. Tests and
examinations that verify critical characteristics are identified by the symbol (C) and major characteristics
by the symbol (M). The number following the classification symbol indicates the serial number of the
test or examination. Tests and examinations which are not annotated with a classification code are
classified minor.
TABLE II. Quality conformance sample size.
Lot size
Sample size
Retained sample
66-110
15
10
111-180
15
10
181-300
20
10
301-500
25
10
5
