MIL-DTL-60277B
TABLE III. Sampling plan.
Lot size
Sample size
Major
Minor
Accept
Reject
Accept
Reject
1 -- 300
100% examination
--
--
--
--
301 -- 800
50
0
1
1
2
801 -- 1800
90
1
2
2
3
6.4 Explosive hazard classification information.
Hazard Classification/Division: 1.4
Storage Compatibility Group: C
DOT Class: C
DOT Marking - Explosive Power Device - Class C - Handle Carefully - Keep Fire Away
6.5 Safety precautions. The safety precaution requirements of "Contractors' Safety Manual for
Ammunition, Explosives, and Related Dangerous Material" (DOD 4145.26M) are applicable and should
be specified in the contract as required by the Federal Acquisition Regulation (FAR) 23.3. NOTE: When
this specification is used as part of the description of work to be accomplished by a Government activity,
the safety precaution requirements of "Ammunition and Explosives Ashore" (OP 5) should be made
applicable.
6.6 Hazard notice. The initiator described herein and certain of its components are flammable,
explosive, or both. Consequently, it presents hazards in manufacture, handling, storage, and shipment.
The contractor should recognize these hazards and take appropriate measures to guard and protect against
fire, explosion, adverse environment, corrosive atmosphere, rough handling, and electrically-induced
incidents.
6.7 Packaging
6.7.1 Packing and marking. Packing and marking should be levels A or B as specified by the
contracting activity:
Level A - In accordance with Drawings 8796826 and 8796827
Level B - In accordance with Drawings 8796826 and 9216824
6.7.1.1 Lot numbers. Lot numbers should be in accordance with MIL-STD-1168.
6.7.2 Air Force packaging. Air Force packaging should be in accordance with TPO F00-138-3770.
6.8 Definitions.
6.8.1 Mechanical failure. Mechanical failure is any deformation or breakage of a part, the occurrence of
which is other than a design function.
6.8.2 Delay time. Delay time is defined as the time from primer impact to the start of pressure rise.
11
