MIL-DTL-50647B
3.5.1 Radiographic examination. Each cartridge assembly shall be radiographically examined for
defects (see 4.7.4).
-4
3.5.2 Leak test. Each assembled cartridge shall exhibit no air leakage greater than 1 x 10 standard
cubic centimeters per second (see 4.7.5) at a 14.7 psia pressure differential.
3.5.3 Vibration. The assembled cartridge shall withstand vibration as prescribed in MIL-STD-810,
Method 514.3, Test Procedure I, Test Condition I 3.2.5 without evidence of any disintegration of the
ignition device, propellant, or igniter, or derangement of any component (see 4.7.7 and 6.2).
3.6 Functional requirements.
3.6.1 Ignition device sensitivity. The ignition device shall fire when drop tested at an energy level of 26
inch-ounces in a sectioned cartridge void of igniter and propellant charge (see 4.7.8.1).
3.6.2 Cartridge performance.
3.6.2.1 Misfires. The cartridge shall not fail to fire.
3.6.2.2 Ballistics. The cartridge, when tested in a M120 initiator shall produce the pressures, delay times
(see 6.6.1), and times to Pmax (see 6.6.2) at temperatures specified in table I (see 4.7.8.2). Pressure values
shall be produced in a one cubic inch pressure station at the end of 15 feet of hose in accordance with
MS-28741-4.
TABLE I. Ballistic requirements.
Temperature (°F)
Delay time (sec)
Pressure (psig)
Time to Pmax (ms)
Lower
Upper
Lower
Upper
-60 to -70
.590
.890
700
1425
50
65 to 75
.590
.780
900
1600
50
195 to 205
.560
.780
1175
1800
50
3.7 Workmanship. Cartridges shall be free of cracks, splits, or other defects which might prevent
proper mating with connecting parts or proper functioning of the device.
3.7.1 Metal defects. All components shall be free from cracks, splits, cold shuts, inclusions, porosity, or
any similar defect.
3.7.2 Burr. No part shall have a burr which might interfere with the assembly or function of the item or
which might be injurious to personnel handling the item.
3.7.3 Foreign matter. No part or assembly shall contain chips, dirt, grease, rust, corrosion, or other
foreign matter.
4
