MIL-D-46606B
-60 to -70
3
4
65 to 75
3
4
195 to 205
3
4
4.4.3 First article failure. Failure of the sample to comply with the requirements of the drawings and
specifications shall result in first article sample disapproval.
4.5 Quality conformance inspection.
4.5.1 Lot.
4.5.1.1 Submission of product. The product shall be submitted in accordance with MIL-STD-105.
4.5.1.2 Lot size. Unless otherwise specified (see 6.2), the production lot size shall be not more than 1200.
4.5.2 Examination and tests. The quality conformance sample shall be subjected to the examinations
of 4.6 and all the test procedures of 4.7 except for 4.7.4.
4.6 Examination. All delay elements and components shall be examined visually and radiographically
and characteristics defined in accordance with the applicable drawings. One hundred percent examination
shall be performed for all critical defects. Examination for major or minor defects shall be performed on a
defect basis in accordance with the classification of defects. Four power (4X) magnification may be used in
performing visual examination for such defects as burrs and foreign matter. When compliance is in doubt as
a result of visual inspection, the characteristic shall be measured or gaged to determine acceptability. All
nonconforming items shall be rejected.
4.6.1 Delay Element, M8, Assembly Drawing 8593163.
Characteristic
Defect
Method of Inspection
Critical
1
Any part missing
X-ray/Visual
2
Improper assembly
X-ray/Visual
3
Primer not properly seated
X-ray/Visual
4
Primer uncrimped or seal missing
Visual
5
Marking missing incorrect or illegible
Visual
Characteristic
Defect
Method of Inspection
Major
101
Concentricity of head with body
Gage
102
Junction of delay body, gasket and primer retainer not
properly sealed
Visual
103
Metal defective
Visual
6
