MIL-DTL-46618C (OS)
3.5.1 Radiographic examination. Each cartridge assembly shall be radiographically examined for defects
(see 4.7.4).
3.5.2 Air tightness. Each assembled cartridge shall exhibit no air leakage greater than 1 x 10-4 standard
cubic centimeters per second (see 4.7.5) at a 14.7 psia pressure differential.
3.5.3 Vibration. The assembled cartridge shall withstand vibration as prescribed in MIL-STD-810,
Method 514.3, Test Procedure I, Test Condition 1-3.2.5 without evidence of any disintegration of the
Ignition Device, propellant, or igniter, or derangement of any component (see 4.7.6 and 6.2).
3.6 Functional requirements.
3.6.1 Ignition Device sensitivity. The Ignition Device shall fire when drop tested at an energy level of 59
inch-ounces in a sectioned cartridge void of igniter and propellant charge (see 4.7.7.1).
3.6.2 Cartridge performance.
3.6.2.1 Misfires. The cartridge shall not fail to fire.
3.6.2.2 Ballistics. The cartridge, when tested in a closed bomb (Drawing 5184857), shall produce the
pressures and ignition delay at temperatures specified in table I (see 4.7.7.2, 6.6.1, and 6.6.2).
TABLE I. Ballistic requirements.
Temperature (°F)
Ignition delay time, max (ms) Maximum pressure (psig)
Time to Pmax (ms)
Lower
Upper
-60 to -70
20
2400
3400
40
65 to 75
20
2400
3400
40
195 to 205
20
2400
3400
40
3.7 Workmanship. Cartridges shall be free of cracks, splits, or other defects which might prevent proper
mating with connecting parts or proper functioning of the device.
3.7.1 Metal defects. All components shall be free from cracks, splits, cold shuts, inclusions, porosity, or
any similar defect.
3.7.2 Burr. No part shall have a burr which might interfere with the assembly or function of the item or
which might be injurious to personnel handling the item.
3.7.3 Foreign matter, No part or assembly shall contain chips, dirt, grease, rust, corrosion, or other foreign
matter.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as follows:
a. First article inspection (see 4.4)
b. Quality conformance inspection (see 4.5)
4.2 Quality assurance terms and definitions. Reference shall be made to ANSI/ASQ Q9000 to define the
quality assurance terms used.
4
