MIL-DTL-85097/14D(OS)
DL4904030
Igniter, Rocket Motor, Mk 189 Mod 1
DL4904294
Igniter, Rocket Motor, Mk 250 Mod 2
DL1517547
Firing Mechanism, Rocket, Mk 28 Mod 2 Assembly
DL1517580
Catapult, Aircraft Ejection Seat, Rocket, Mk 1 Mod 1, Loaded Assembly
(Application for copies of specifications and drawings should be addressed to the Commander, Indian Head
Division, Naval Surface Warfare Center, Attn: Code 8410P, 101 Strauss Avenue, Indian Head, MD 20640-
5035.)
3. REQUIREMENTS
3.1 General. The requirements in this specification sheet, unless in direct conflict with the basic
specification, shall be considered additional, not substitute. The loaded rocket catapult shall conform to the
documents specified herein and the applicable documents listed on DL4904294, DL4904030, DL1517547,
and DL1517580.
3.2 Preproduction/production.
3.2.1 Ballistic performance. The rocket catapult shall meet the requirements of tables I and II when test
fired using an ejected weight of 317 pounds (see 6.3 for definitions).
TABLE I. Static firing requirements for booster.
Firing Temperatures
40 F
160 F
Performance requirements
Max
Min
Max
Min
Ignition delay (ms)
30
0
30
0
Maximum acceleration (g)
11
--
20
--
Onset rate (g/s)
200
--
350
--
Separation velocity (ft/s)
--
30
--
45
Launch time (ms)
260
--
170
--
4. QUALITY ASSURANCE PROVISIONS
4.1 Preproduction.
4.1.1 Sample size. Twenty rocket catapults shall be submitted for preproduction inspection and tested in
accordance with table III of MIL-A-85097.
