MIL-DTL-82884A
TABLE II. Quality conformance tests and examinations.
Item
Nature of test
Requirement
Test paragraph
Classification
paragraph
(DOD-STD-2101)
Primary component
Single lot verification
3.4
4.4.1
(M101)
Ignition device
Age, loading, and acceptance
3.4.1
4.5.1
(M102)
Ignition device
Radiographic examination
3.4.1.1
4.5.2
(M103)
Propellant
Acceptance and weight
3.4.2
4.5.1 and 4.5.3
(M104)
Cartridge
Visual examination
3.7
4.5.4
(M105)
Cartridge
Leakage
3.5.1
4.5.5
(M106)
Cartridge
Radiographic examination
3.5.2
4.5.6
(M107)
Cartridge
Ballistics tests
3.6
4.5.7
(M108)
Cartridge
Preservation-packaging, and
Section 5
4.6
(M109)
marking
TABLE III. Quality conformance sample size.
Lot size
Test sample size
Retained sample
Total selected
151-280
32
10
42
281-500
50
10
60
501-1200
80
10
90
1201-3200
125
10
135
4.5 Tests.
4.5.1 Ignition device verification. Verification shall be provided that the ignition devices used were
manufactured, loaded, and accepted in accordance with the requirements of 3.4.1 (see 6.4).
4.5.2 Ignition device radiographic examination. All ignition devices shall be radiographically examined in
accordance with MIL-STD-453; those having any of the defects specified in 3.4.1.1 shall be rejected. Pressure-
sensitive tape may be used as an aid in positioning the ignition devices in suitable grooved racks. For the most
revealing exposure, the ignition devices shall be laid on their side with the anvil cutouts vertical.
4.5.3 Propellant condition. Propellant shall be inspected in accordance with the applicable paragraphs of OP
5. Evidence of decomposition shall be cause for rejection.
6
