MIL-DTL-60567C
TABLE I. Ballistic requirements.
Ignition delay time
Temperature
(sec)
(°F)
-60 to -70
0.350 ± 100
65 to 75
0.300 ± 0.50
195 to 205
0.250 ± 100
3.7 Workmanship. Delay elements shall be free of cracks, splits, or other defects which might prevent
proper mating with connecting parts or proper functioning of the device.
3.7.1 Metal defects. All components shall be free from cracks, splits, cold shuts, inclusions, porosity, or
any similar defect.
3.7.2 Burr. No part shall have a burr which might interfere with the assembly or function of the item or
which might be injurious to personnel handling the item.
3.7.3 Foreign matter. No part or assembly shall contain chips, dirt, grease, rust, corrosion, or other
foreign matter.
4. VERIFICATION
4.1 Classification of inspections. The inspection requirements specified herein are classified as follows:
a. First article inspection (see 4.4)
b. Quality conformance inspection (see 4.5)
4.2 Quality assurance terms and definitions. Reference shall be made to ANSI/ASQ A8402 to define
the quality assurance terms used.
4.3 Inspections. Inspections shall be in accordance with MIL-A-2550 and ASTM E 1742.
4.3.1 Inspection conditions. Unless otherwise specified in the contract or purchase order (see 6.2),
inspection conditions shall be as follows:
a. Temperature: Room ambient 20 to 25 °C (68 to 77 °F)
b. Altitude: Sea level
c. Humidity: 50 percent relative, maximum
d. Atmospheric: 14.7 psia
4.4 First article inspection. At the beginning of regular production, the supplier shall submit a first
article sample to a Government approved facility for evaluation. The sample shall consist of 23 delay
bodies, 23 ignition device retainers to be tested as indicated in table II, and 10 sets of unassembled
components (including explosive components) for visual and dimensional examination. The first article
sample shall be manufactured using the same materials, equipment, processes, and procedures as used in
regular production. All parts and materials, including packaging and packing, shall be the same as used
for regular production and shall be obtained from the same source of supply. When it becomes necessary
4
